Length: 36.58 m. (12 ft) Width: 12.19 m. (40 ft) Side depth: 1.98 m. (6.5 ft) Machinery: Liebherr 36 - 115 ton Deck area: 440 m2 Approx. Capacity: 525 ton at 0.4m freeboard Spud legs: 4 - Ø762 x 25mm
Length: 48.77 m. (160 ft) Width: 29.29 m. (96 ft) Side depth: 2.44 m. (8 ft) Machinery: Soilmec SC-120 - 150 ton Deck area: 1420 m2 Approx. Capacity: 2175 ton at 0.4m freeboard Spud legs: 4 - Ø762 x 25mm
Length: 24.38 m. (80 ft) Width: 17.07 m. (56 ft) Side depth: 1.98 m. (6.5 ft) Machinery: Bauer 36 - 135 ton Deck area: 415 m2 Approx. Capacity: 475 ton at 0.4m freeboard Spud legs: 4 - Ø762 x 25mm
Length: 32.92 m. (108 ft) Width: 9.75 m. (32 ft) Side depth: 1.98 m. (6.5 ft) Machinery: ABI TM 22 - 78 ton Deck area: 310 m2 Approx. Capacity: 365 ton at 0.4m freeboard Spud legs: 4 - Ø762 x 25mm
Length: 36.58 m. (120 ft) Width: 19.51 m. (64 ft) Side depth: 2.44 m. (8 ft) Machinery: Woltman A-900-HPDR - 120 ton Deck area: 710 m2 Approx. Capacity: 1075 ton at 0.4m freeboard Spud legs: 4 - Ø762 x 25mm
Length: 30.48 m. (100 ft) Width: 17.07 m. (56 ft) Side depth: 1.98 m. (6.5 ft) Machinery: Hillcon HSCX700GLS - 136 ton Deck area: 520 m2 Approx. Capacity: 600 ton at 0.4m freeboard Spud legs: 4 - Ø762 x 25mm
